MedTouch Image Discrimination Protocol
Pre-written protocol for Med-PC 6 Behavioral Control Software as a starting point, modify it to suit your needs.
Medstate Notation (MSN) commands include:
- MEDTouch_SetPort/SetRack
-
- Informs the driver which port to use for the interface card, and which rack holds it.
- NOTE: Command should be sent before the MEDTouch_Init() command and is only needed when the IC-124 cards are not in Rack 1 or the IC-124 ports are not set to the default Port.
- Informs the driver which port to use for the interface card, and which rack holds it.
- MEDTouch_Init/MEDTouchRPO_Init
- Informs the device which aperture plate to use.
- MEDTouch_DisplayImage
- Informs the device which location/slot to display the specified image in.
- MEDTouch_CLEARImage
- Informs the device to clear the image that is displayed at the specified slot #.
- NOTE: This command is the same as MEDTouch_DisplayImage(MG, BOX, Slot#, 0) or MEDTouchRPO_DisplayImage(MG, Rack, Port, Offset, BOX, Slot#, 0).
- Informs the device to clear the image that is displayed at the specified slot #.
- MEDTouch_SHOW
- Used to update the Med-PC SHOW fields with information about which images are being displayed in each location on the device.`
